specification |
---|
colour | matt granite chalk/rose
| cassette | sram pg-1230 eagle, 11-50, 12 speed
|
frame | 6061 alloy, scr aluminium front triangle with tapered head tube, iscg 2 guide mounts, alloy symmetrical scr rear triangle, shape.It and 148mm boost dropouts
| chain | sram GX eagle, 12 speed
|
fork | rockshox pike select rc 27.5", 140mm travel, 37mm offset, debonair, charger rc damper, fast black coating, tapered steerer, 110mm x 15mm boost, maxle ultimate
| crankset | sram x1 eagle, x-sync 2, direct mount 32t, dub, 170mm, boost, 12 speed
|
rear shock | rockshox deluxe select + rt, debonair, fast black coating, adjustable rebound and 2 position compression
| bottom bracket | sram dub, bsa, 73mm
|
headset | fsa no. 57 orbit zs, acb, 1 1/2" lower and 1 1/8" upper sealed cartridge bearings
| seatpost | whyte drop.It ii adjust, 30.9mm, s/m 120-150mm travel, l/xl 140-170mm travel, paddle remote lever
|
rear hub | alloy, double sealed cartridge bearings, centrelock, 12mm x 148mm boost thru axle, 32 hole
| saddle | whyte custom, dual density, triple panel design
|
front hub | alloy, double sealed cartridge bearings, centrelock, 15mm x 110mm boost thru axle, 31mm torque caps, 32 hole
| handlebar | whyte 6061 alloy, 31.8mm, s 15mm rise, 760mm wide, m/l/xl, 30mm rise 780mm wide
|
spokes | dt swiss champion 2.0mm, black stainless, brass nipples
| stem | whyte gravity stem, 35mm extension
|
rims | wtb st i30 tcs 2.0 system, pinned joint, tubeless ready, 32 hole
| grips | whyte lock-on enduro grip
|
tyre | maxxis minion dhf tr 27.5" x 2.6" 120tpi, exo sidewall protection, 3c maxx terra, front, maxxis dissector tr 27.5" x 2.6" 60tpi, exo+ sidewall protection, rear
| brakes front | sram guide g2 r, 4 piston, 180mm disc
|
shift levers | sram GX eagle, mmx clamp, 12 speed
| brakes rear | sram guide g2 r, 4 piston, 180mm disc, internal routing
|
front mech | n/a | brake levers | sram guide g2 r, matchmaker
|
rear mech | sram GX eagle, 12 speed
| pedals | none |
weight | 14.6 kg
| | |
